Description
Square wire mesh, also called woven wire mesh, is available in various specifications to meet different industrial and commercial requirements. Below are the key specifications typically associated with square wire mesh:
Material:
Stainless Steel: Common grades include 304, 304L, 316, and 316L for superior corrosion resistance and durability.
Galvanized Steel: Provides excellent protection against rust and corrosion, ideal for outdoor applications.
Low Carbon Steel: Cost-effective and strong, suitable for applications where corrosion resistance is not a primary concern.
Brass or Copper: Used for decorative purposes or specific industrial applications requiring non-ferrous materials.
Wire Diameter (Gauge):
Ranges from 0.5 mm to 2.5 mm (or 24 to 12 gauge).
The thickness of the wire can be selected based on the required strength and application.
Mesh Opening Size:
Ranges from 2 mesh (2 openings per inch) to 60 mesh (60 openings per inch).
The size of the square openings can be adjusted depending on the level of filtration, security, or visibility needed.
Roll Width and Length:
Standard roll widths are 1 meter, 1.2 meters, 1.5 meters, 3ft, 4ft and 5ft, but custom widths can be produced upon request. Roll lengths typically range from 10 meters to 30 meters.
Surface Treatment:
Galvanized: Available in both hot-dip and electro-galvanized options for enhanced rust resistance.
PVC Coated: Provides additional protection and comes in various colors for aesthetic or functional purposes.
Polished or Bright Annealed: For a smooth and shiny finish, particularly for stainless steel mesh.
Edge Finish:
Cut Edges: Standard option where the mesh is cut to size.
Selvage Edges: Reinforced edges to prevent unraveling and improve durability, especially in fencing applications.
Tensile Strength:
Varies depending on the material and wire diameter, ensuring the mesh can withstand specific loads or pressures.
Applications:
- Construction:Concrete reinforcement, fencing, plastering.
- Filtration:The woven wire mesh cloth is used in water and air filtration, sieving of particles.
- Industrial:Machinery protection, ventilation, screening.
- Agriculture:Animal enclosures, crop protection.
- Decorative:Architectural features, interior design elements.
At Anping Unicorn Metal Products Co., Ltd, we can customize square weaving mesh to your exact specifications, ensuring you get the ideal product for your application. Whether you need high-strength mesh for industrial use or finer mesh for filtration, we have the expertise and manufacturing capabilities to deliver top-quality solutions.
